Specification
| Volt | 12V |
| Power | 1.2KW |
| Teeth | 15T |
| Rotation | CW |
OE NO
| Denso | 438000-2410 |
Ref No
| GM | 12663052 |
| OPEL | 95525318 |
| LESTER | 10700 |
| LUCAS | LRS04178 |
Adapted models
| OPEL Insignia 2.0L B20NFT 2017- |
Components
Mounting type
| Mount Hole Dia | 10mm, 10mm |
| Flange Dia | 75mm |
| Mount Holes Cnt to Cnt | 94mm |
| Pinion Dia | 38mm |
| Out of Mesh Clearance | 24mm |
| Overall Length | 219mm |
| HSG Length | 155mm |
| Rest Position B | 148.5mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG | 3.4Kg |
