Specification
| Volt | 12V |
| Power | 1.0KW |
| Teeth | 9T |
| Rotation | CW |
OE NO
| Denso | 028000-5900 |
Ref No
| TOYOTA | 28100-34060 |
| LESTER | 16737 |
| LUCAS | LRS00607 |
Adapted models
| TOYOTA Land Cruiser 2.4L 22R (RJ70/73) 1984-89 |
Components
Mounting type
| Mount Hole Dia | 11.5mm, 11.5mm |
| Flange Dia | 74mm |
| Mount Holes Cnt to Cnt | 114.5mm |
| Pinion Dia | 29mm |
| Out of Mesh Clearance | 18mm |
| Overall Length | 188mm |
| HSG Length | 133mm |
| Rest Position B | 158mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG |
